Shrinkable Film Blowing Machine
The machine plasticizes two kinds of the same or different materials into the co-extruded composite head through two extruders to produce the co-extruded composite film, which greatly improves the physical properties of the film, increases its strength, and makes the film have good barrier property and air tightness.
Category:
Product Description
Keywords:
The machine plasticizes two kinds of the same or different materials into the co-extruded composite head through two extruders to produce the co-extruded composite film, which greatly improves the physical properties of the film, increases its strength, and makes the film have good barrier property and air tightness.
The machine adopts advanced continuous rotating head, the product is smooth, the uniformity is good, to ensure the packaging machine, printing machine and other subsequent process equipment on the film quality requirements, suitable for the production of composite pearl film, composite liquid packaging film, insulation film, multi-functional agricultural film and so on. Its application scope is gradually expanding, is the direction of the development of plastic products.
|
Model |
SJ-50*2-700 |
SJ-55*2-1000 |
SJ-60*2-1350 |
SJ-50*2-700 |
|
Screw Diameter |
Φ50*2 |
Φ55*2 |
Φ60*2 |
Φ65*2 |
|
Screw ratio L/D |
30:1 |
30:1 |
30:1 |
30:1 |
|
Screw Speed |
15-120r/min |
15-120r/min |
15-120r/min |
15-120r/min |
|
Main Motor Power |
15kw*2 |
18.5kw*2 |
22kw*2 |
30kw*2 |
|
Extrusion output(single) |
60kg/h |
80kg/h |
120kg/h |
160kg/h |
|
Rang of die |
Φ80 Φ160 |
Φ120 Φ200 |
Φ150 Φ250 |
Φ220 Φ350 |
|
Single-sided thickness of film |
0.015-0.15mm |
0.015-0.15mm |
0.015-0.15mm |
0.015-0.15mm |
|
Max folding width of film |
800mm |
1000mm |
1200mm |
1500mm |
|
Electric total capacity |
60kw |
72kw |
88kw |
110kw |
|
Overall dimension |
5000×3000×4800 |
5500×3500×5800 |
6800×4300×6000 |
6500×4500×7000 |
|
Weight of machine |
4.5T |
5.5T |
6.85T |
7.5T |
